Brief  introductionThe pump is made on the basis of circulating water multi-purpose vacuum pump, and in view of the small space of the lab, with reference to the Japan-made bench type pump, made with reduced size and improvement, and adopting one-shot forming, it has the feature of small size, light weight and beautiful appearance and so on, two meters two taps, four meters four taps .identical dual size multi-purpose vacuum pump, while the teacher is demonstrating, student can also turning on or off the machine on any size of it.


Main features:

1. Energy-saving:
Save more than 35% of electricity than other types of vacuum pump.
2. Recycling:
Cyclically use water, save the precious water resources.
3. Noise-reducing:
The fluid muffler can reduce the water vapor, make the higher vacuum degree and more stable, lower noise.
4. Resisting:
Resist corrosion by acid, alkali and solvents.
5. Good sealing:
Fluorine rubber sealing, the inner of the machine can't be intruded by corrosive gas.
6. Water-changing conveniently:
Replace the water in the flume regularly to ensure the purity of water quality, the vacuum degree and to avoid dirt stains


Technical Data

ModelSHZ-D(III)SHZ-D(III)Four-meter for tapRemark
Power(W)180370Can equipped with 2L,5L glass reactor or rotary evaporator.The vacuum is better when the water temperature is between 4℃ and 10℃.
Voltage(V/Hz)220/50 or 110/60
Flow(L/min)60
Lift(m)8
Body materialAnti-corrosion/1Cr18Anti-corrosion
Max Pressure(Mpa)0.098
Sucking rate for single tap(L/min)10
Quantity of tap(Psc)24
Tank capacity(L)15
Dimension(mm)400*280*420
Weight(kg)15
Ultimate vacuum(Kpa)26
Security performanceAnti-corrosion、counter-current prevent valve
